Level Range: 4,6,8,10,12,15,20,30m
Accuracy: 0.5%-1.0%
Resolution: 3mm or 0.1%
Display: LCD Display
Analog Output: Two Wires 4-20mA/250Ω Load
Ultrasonic level meter is based on the Time-of-Flight principle. A sensor emits ultrasonic pulses, the surface of the media reflects the signal and the sensor detects it again. The Time-of-Flight of the reflected ultrasonic signal is directly proportional to the distance traveled. With the known tank geometry the level can be calculated.
Price-favourable solution for simple applications.
Maintenance-free operation through non-contact measuring principle.
Reliable measurement independent of product features.
Ultrasonic level meter for continuous level measurement of liquids or bulk solids. Typical applications are the measurement of liquids in storage tanks or open basins. The sensor is also suitable for the detection of bulk solids in small vessels or open containers. The non-contact measuring principle is independent of product features and allows a setup without medium.
| Function | Compact Type |
| Level Range | 4, 6, 8, 10, 12, 15, 20, 30m |
| Accuracy | 0.5% - 1.0% |
| Resolution | 3mm or 0.1% |
| Display | LCD Display |
| Analog Output | Two Wires 4-20mA / 250Ω Load |
| Power Supply | DC24V |
| Environmental Temperature | Transmitter: -20~+60°C, Sensor: -20~+80°C |
| Communication | HART |
| Protection Class | Transmitter IP65 (IP67 Optional), Sensor IP68 |
| Probe Installation | Flange, Thread |
